PTFE Coated Fiberglass Mesh

Brand: WELLFLON
Materials: PTFE (Teflon), Fiberglass Mesh
Yarn Type: Filament Yarn/Texturized Yarn
Width Range: 1000~4000mm
Mesh Size: Custom Mesh Size
Features: Non-stick, High-Temp Resistant
Temp. Resistance: -70°C to +280°C
Color: Brow/Black/White /Custom Color
Certification: FDA/LFGB/SGS/RoHS/UL

WellFlon® PTFE Coated Fiberglass Mesh made of high-strength glass fiber or Kevlar as the base material, is woven into a high-strength mesh base fabric to provide strength and dimensional stability for PTFE fiberglass mesh. By coating Teflon resin, PTFE Coated provides temperature resistance, chemical resistance, antistatic and anti-stick properties for mesh fabrics. The continuous operating temperature of PTFE coated fiberglass open mesh fabric can reach -70 – 260 ℃, and it can be reinforced with stainless steel to increase the temperature resistance and durability further.

Different Types of Open Mseh for PTFE Coated Fiberglass Mesh:

Main Characteristics of PTFE Coated Fiberglass Mesh:

1. Breathability and Dimensional Stability: Air permeability of the mesh belts reduces heat source consumption and improves drying efficiency. At the same time, the vertical weaving process and the strength of the glass fiber fabric ensure that the mesh cloth can have high tear strength and dimensionalstability and is suitable for various wheel diameters.Viscous Stable The upgraded glue formula has muscular bonding strength, and it still has good adherence even on high-temperature surfaces, and it is not easy to tear off the glue residue.

2. Non-stick and Non-toxic: The excellent anti-friction coefficient makes the PTFE open mesh belt not afraid of oil and water. At the same time, in an environment of more than 315 degrees Celsius, PTFE will only vaporize into a colorless, odorless, and non-toxic gas.

3. Resistant to High and Low Temperatures and Maintains Softness: 196℃～260℃ can be used directly and continuously, anti-aging and weathering simultaneously.In the temperature range, the softness of the PTFE mesh fabric does not change significantly

4. Chemical Resistance: PTFE open mesh fabric has excellent chemical inertness and does not react with acid and alkali liquids, so that can be used in various corrosive and alkali liquids.

5. Dimensional Stability: At -70 – 260 ℃, the elongation of PTFE mesh glass fiber fabric does not exceed 5‰, and at the same time, the warp and weft directions have high tensile strength and excellent durability.

6. Bending Fatigue Resistance: The PTFE mesh fabric has excellent resistance to bending fatigue coefficient, making it suitable for machines of various small wheel diameters.

Main Application of PTFE Coated Fiberglass Mesh:

PTFE fiberglass mesh fabric has been developed for high-temperature, anti-stick, dry, high-strength applications such as food-grade conveyor belts, dryers, and household barbecue nets. PTFE mesh can also be manufactured into UV curing machine open mesh belts, microwave dryer conveyor belts, screen printing conveyor belts, photovoltaic industry stringer conveyor belts, and other applications.

Main Specifications of PTFE Coated Fiberglass Mesh:

Item	Mesh Size	Material	Thickness	Weight	Temperature	Max Width	Tensile Strength
CWM-1010	1x1mm	Fiberglass	0.5mm	370g/m2	-70 ～ 320 ℃	4000mm	310/290N/cm
CWM-2020	2x2mm	Fiberglass	0.7mm	450g/m2	-70 ～ 320 ℃	4000mm	350/310N/cm
CWM-4040A	4x4mm	Fiberglass	1.0mm	400g/m2	-70 ～ 320 ℃	4000mm	390/320N/cm
CWM-4040E	4x4mm	Fiberglass	1.0mm	450g/m2	-70 ～ 320 ℃	4000mm	390/320N/cm
CWM-4040KB	4x4mm	Kevlar/Fiberglass	1.2mm	600g/m2	-70 ～ 320 ℃	4000mm	895/370N/cm
CWM-4040H	4x4mm	Fiberglass	1.0mm	500g/m2	-70 ～ 320 ℃	4000mm	395/370N/cm
CWM-4040K	4x4mm	Fiberglass	1.0mm	500g/m2	-70 ～ 320 ℃	4000mm	900/600N/cm
CWM-4040S	4x4mm	Fiberglass	1.0mm	550g/m2	-70 ～ 320 ℃	4000mm	395/370N/cm
CWM-100100	10x10mm	Fiberglass	1.2mm	450g/m2	-70 ～ 320 ℃	4000mm	360/300N/cm
CWM-0510	0.5x1mm	Fiberglass	0.5mm	420g/m2	-70 ～ 320 ℃	4000mm	310/290N/cm
CWM-2025	2x2.5mm	Fiberglass	0.9mm	600g/m2	-70 ～ 320 ℃	3000mm	390/320N/cm
